Touch Switch
VL-A801NY-2BG
Color
Series
C7 EU Standard
C9 US/AU Standard
A8 US Standard
B6 UK Standard
Panel Type
Full Glass
Frame glass
Switch Button
1 Gang 2P
1 Gang 3P
3 Gang 6P
4 Gang 8P
Function
Switch
Curtain Motor
Smart
Basic
Wi-Fi
EC
2 Way
1 Way
2 Way
Advantages
Glass touch controlsSmart HomeRemote control by phoneScene LinkageNeutral & Live Wire Power SupplyAuto-Restore After Power OutageCompatible with IOS & AndroidEasy to use
Product Description
Elevate your home with the Livolo A8 WiFi Touch Switch, a sleek black glass panel that brings modern convenience to your daily routine. Control your lights effortlessly via the elegant touch surface or from anywhere using the Livolo app on your smartphone. Perfect for busy mornings or cozy evenings, this switch integrates seamlessly into your smart home ecosystem, allowing you to set scenes and schedules. Safety is prioritized with neutral and live wire power supply, ensuring stable performance. The two-color LED indicator provides clear status, while the auto-restore feature keeps your settings intact after power outages. Experience comfort and control at your fingertips with this stylish addition to any room.
Touch Switch_front_view
Touch Switch_slide_view
Touch Switch_back_view
Product Composition
• LIVOLO | A8 1-Gang 2-Position Black Full Glass Touch Panel
x1
• LIVOLO | 2-Position 1-Gang Neutral WiFi Black Functional Module
x1
Technical Specifications
Brand
LIVOLO
Series
A8 US Standard
Panel Style
Full Glass
Gang/Position
1 Gang 2P
Way
1 Way
Smart Type
Wi-Fi
Function
Switch
Material
Tempered Glass
Panel Dimension
130mm × 88mm × 8mm
Dimension
Full glass touch switch: 46.5*46.5*36.75mm Modular touch switch: 45.1*45.1*42.6mm
Voltage
100-240V~ 50/60Hz
Status indication
Two-color LED light + Buzzer
Load
5A/1 gang, total no more than 10A
Longevity
100,000 times
Temperature and humidity
-10℃ - +40℃
WiFi communication protocol
IEEE802.11 b/g/n protocol TCP/IP protocol stack
Two way function
Yes
Retardant shell
Yes
Installation Orientation
Horizontal/Vertical
Panel Color
Black
