Touch Switch
VL-C701Y-2IG
Color
Series
Panel Type
Switch Button
Function
Smart
2 Way
Advantages
Glass touch controlsSmart HomeRemote control by phoneEasy to useModern DesignScene LinkageProduct Description
Elevate your home's intelligence with the LIVOLO C7 Smart WiFi Touch Switch, featuring a sleek gray full-glass panel that seamlessly integrates into modern interiors. Control lighting effortlessly via the LIVOLO app from anywhere—turn off lights left on, schedule routines to simulate presence, or link with other smart devices for synchronized scenes. The responsive glass touch surface offers instant, gentle control, while the two-color LED and buzzer provide clear status feedback. Designed for daily comfort and safety, this switch enhances your lifestyle by merging elegant design with reliable smart home automation, ensuring convenience at your fingertips.
Product Composition
• LIVOLO | C7 1-Gang 1-Touch Gray Panel
x1
• LIVOLO | 2-Position 1-Switch Single Control Touch Neutral-Live WiFi Functional Module | Glass Version
x1
Technical Specifications
Brand
LIVOLO
Series
C7 EU Standard
Panel Style
Full Glass
Gang/Position
1 Gang 2P
Way
1 Way
Smart Type
Wi-Fi
Function
Switch
Material
Tempered Glass
Panel Dimension
80mm × 80mm × 8mm
Dimension
Full glass touch switch:
46.5*46.5*36.75mm
Modular touch switch:
45.1*45.1*42.6mm
Voltage
100-240V~ 50/60Hz
Status indication
Two-color LED light + Buzzer
Load
5A/1 gang,
total no more than 10A
Longevity
100,000 times
Temperature and humidity
-10℃ - +40℃
WiFi communication protocol
IEEE802.11 b/g/n protocol
TCP/IP protocol stack
Two way function
Yes
Retardant shell
Yes
Installation Orientation
Horizontal/Vertical
Panel Color
Gray
Compatible with standard round or square wall boxes
All products require installation in round/square wall boxes with a minimum depth of 40mm.
