Touch Switch
VL-C9F1S/F1S-6EP
Color
Series
C7 EU Standard
C9 US/AU Standard
A8 US Standard
B6 UK Standard
Panel Type
Full Glass
Frame glass
Switch Button
1 Gang 2P
1 Gang 3P
1 Gang 4P
1 Gang 7P
2 Gang 6P
Function
Switch
Curtain Motor
Smart
Basic
Wi-Fi
EC
2 Way
1 Way
2 Way
Advantages
Glass touch controlsBreathing LED IndicatorModern DesignSmart HomeEasy to useElegant hotel-style designAuto-Restore After Power OutageScene Linkage
Product Description
Experience seamless control over your home lighting with the LIVOLO C9 Green Touch Switch. This elegant, two-gang switch allows you to manage two separate light circuits from a single panel, perfect for living rooms or hallways where multiple light sources need independent control. The tempered glass surface adds a touch of modern sophistication, while the two-color LED indicator and buzzer provide clear status feedback. With basic smart functionality, it integrates effortlessly into your daily routine, offering convenience and safety through its flame-retardant shell and long 100,000-cycle lifespan. Whether you're dimming the lights for a movie night or brightening the kitchen, the LIVOLO C9 brings smart, stylish control to your fingertips.
Touch Switch_front_view
Touch Switch_slide_view
Touch Switch_back_view
Product Composition
• LIVOLO | C9 2-Gang 2-Hole 6-Position Green Frame Glass Touch Panel
x1
• LIVOLO | 6-Position 1-Gang 2-Way Green Functional Module
x2
Technical Specifications
Brand
LIVOLO
Series
C9 US/AU Standard
Panel Style
Frame glass
Gang/Position
2 Gang 6P
Way
2 Way
Smart Type
Basic
Function
Switch
Material
Tempered Glass
Panel Dimension
119mm × 130mm × 8mm
Dimension
Full glass touch switch: 46.5*46.5*38.75mm 69.6*47*28.9mm Modular touch switch: 45.1*45.1*42.6mm
Voltage
100-240V~ 50/60Hz
Status indicator
Two-color LED light + buzzer
Temperature and humidity
-10℃ - +40℃
Minimum load
5W
Load
5A/each gang, total no more than 10A
Flame retardant shell
Longevity
100,000 times
Two way function
Y-O
Installation Orientation
Horizontal/Vertical
Panel Color
Green
Compatible with standard round or square wall boxes
All products require installation in round/square wall boxes with a minimum depth of 40mm.
