Smart European Power Socket
VL-P7E-2I1x VL-FCTC16AZ2-2IP
Color
Advantages
Directly available from stockGlass touch controlsPower Consumption MonitoringAuto-Restore After Power OutageSmart Home
Product Description
LIVOLO smart European sockets redefine the wisdom of electricity use with technology - you can remotely control the switches of home appliances through the mobile phone APP without getting up, and control the power of the whole house with a touch of your fingertips; the real-time power detection function accurately tracks the working status of the equipment; the custom timing mode allows the water heater to heat on time, and you can enjoy comfort when you return home; it also supports smart linkage scenes, when it detects that the coffee machine has finished preheating, the information is pushed, or when the theater equipment is turned on, the smart curtains are closed synchronously, creating a seamless smart life experience. LIVOLO uses hard-core technology to upgrade traditional sockets to home energy centers, so that every kilowatt-hour of electricity can release its value in safe, efficient and humanized control.
Product Composition
• LIVOLO | Panel | Gray | Single frame glass panel
x1
• LIVOLO | Module | Gray | EC smart EU socket
x1
Technical Specifications
Brand
LIVOLO
Control Method
Touch Control
Operation Type
Short Press On/Off, Long Press Pairing Mode
Switch Button
1 Gang
Panel Color
Gray
Material
PC Flame-Retardant Material
Backlight
Red/Blue LED
Dimensions
80 x 80 x 4mm
Installation Depth
39mm
Voltage
100-240V AC, 50/60Hz
Power failure recovery
Yes
Neutral Wire Required
Yes
Protection standard
IP20
Max Current
16A
Life time of on/off
50000 times
Power Detection Function
Yes
Power Detection Error
≤2%
Child safety door
Yes
Relative Humidity
95% RH
Operating Temperature
-10℃ to +40℃
Wall Box Type
Round/Square (Mounting Hole 60mm)
Applicable to
Single Wall Box
Installation Orientation
Horizontal/Vertical
Compatible with standard round or square wall boxes
All products require installation in round/square wall boxes with a minimum depth of 40mm.
